Description The ICP DAS PCI-1202 series is a family of high performance data acquisition boards that feature continuous gap-free data acquisition in DOS at 110 kHz for low gain. The PCI-1202 family has the same hardware architecture as the PCI-1802, and provides 32-channel single-ended or 16-channel differential Analog Inputs. As with the PCI-1802 family, the PCI-1202 series features both the Magic Scan and Continuous Capture functions. The PCI-1202LU Universal PCI card supports both the 3.3 V and the 5 V PCI bus. The PCI-1202LU cards are fully compatible with PCI-1202L cards and are designed as direct replacements without requiring any modification to the software or the driver, with the main difference being the addition of DI pull-high/low resistors and a Card ID switch on the PCI-1202LU. The PCI-1202LU/8K cards are equipped with an 8K-sample hardware FIFO that reduces data overflow issues in multi-tasking environments such as Windows and Linux. Lead time: 5-7 working days from receipt of order.
